FDFMA2P853 Real Image FDFMA2P853 label picture FDFMA2P853 real image
Same model may have multiple batches, images only for reference.
FDFMA2P853 Real Image FDFMA2P853 label picture FDFMA2P853 real image
FDFMA2P853 Real Image FDFMA2P853 label picture FDFMA2P853 real image
Same model may have multiple batches, images only for reference.

FDFMA2P853

Part No FDFMA2P853
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 20V 3A MICROFET6
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 3A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 1.8V, 4.5V
Gate-Source Threshold Voltage 1.3V @ 250μA
Max Gate Charge 6nC @ 4.5V
Max Input Capacitance 435pF @ 10V
Maximum Gate-Source Voltage ±8V
FET Feature Schottky Diode (Isolated)
Power Dissipation (Max) 1.4W (Ta)
Maximum Rds On at Id,Vgs 120 mOhm @ 3A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 6-MicroFET (2x2)
Dimension 6-VDFN Exposed Pad
Win Source Part Number 015970-FDFMA2P853
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FDFMA2P853 CAD Model

Description

Description for FDFMA2P853

The FDFMA2P853 is engineered for high-performance applications, offering a unique balance of efficiency and robust construction in a P-channel MOSFET package.

  • Applications: Power management units, Smart grid technologies, Portable electronics
  • Features: High power density, Fast switching speed, Durable construction
  • Benefits: Increased performance, Extended device longevity, Reliable under high load

Additional Details: Supports various mounting options, Made with environmentally responsible materials, Fully certified for industrial usage.
