FDG328P Real Image FDG328P label picture
Same model may have multiple batches, images only for reference.
FDG328P Real Image FDG328P label picture
FDG328P Real Image FDG328P label picture
Same model may have multiple batches, images only for reference.

FDG328P

Part No FDG328P
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET P-CH 20V 1.5A 6-Pin SC-88 T/R / MOSFET P-CH 20V 1.5A SC70-6
Datasheet
FDG328P Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 1.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 6nC @ 4.5V
Max Input Capacitance 337pF @ 10V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 750mW (Ta)
Maximum Rds On at Id,Vgs 145 mOhm @ 1.5A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SC-70-6
Dimension 6-TSSOP, SC-88, SOT-363
Win Source Part Number 015981-FDG328P
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 3k pcs
Family Name FDG328P
Introduction Date February 20, 2001
ECCN EAR99
Country of Origin China, Philippines
Halogen Free Compliant
Estimated EOL Date 2021
Ultra Librarian 3D Model Ultra Librarian FDG328P CAD Model

Description

The Fairchild/ON Semiconductor FDG328P is a P-Channel MOSFET designed for general purpose applications. It has a high popularity and balanced supply and demand.

  • Drain-Source Breakdown Voltage: 20V
  • Continuous Drain Current: 1.5A @ 25°C
  • Package: SC-70-6
  • Power Dissipation: 750mW (Ta)
  • Gate-Source Threshold Voltage: 1.5V @ 250μA
  • Rds On (max): 145 mOhm @ 1.5A, 4.5V
