FDG6303N Real Image FDG6303N Real Image1 FDG6303N Real Image2 FDG6303N Real Image3
Same model may have multiple batches, images only for reference.
FDG6303N Real Image FDG6303N Real Image1 FDG6303N Real Image2 FDG6303N Real Image3
FDG6303N Real Image FDG6303N Real Image1 FDG6303N Real Image2 FDG6303N Real Image3
Same model may have multiple batches, images only for reference.

FDG6303N

Part No FDG6303N
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2N-CH 25V 0.5A SC70-6
Datasheet
FDG6303N Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 25V
Continuous Drain Current at 25°C 500mA
Maximum Rds On at Id,Vgs 450 mOhm @ 500mA, 4.5V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 2.3nC @ 4.5V
Max Input Capacitance 50pF @ 10V
Maximum Power Dissipation 300mW
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SC-70-6
Win Source Part Number 015984-FDG6303N
Family Name FDG6303N
Introduction Date August 06, 1999
ECCN EAR99
Country of Origin China, Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FDG6303N CAD Model

Description

The FDG6303N is a 2 N-Channel Dual FET manufactured by Fairchild/ON Semiconductor. It features a logic level gate and is designed for use in discrete semiconductor products.

  • Mounting: Surface Mount Device (SMD)
  • Power Dissipation: 300mW
  • Drain-Source Breakdown Voltage: 25V
  • Continuous Drain Current: 500mA @ 25°C
  • Gate-Source Threshold Voltage: 1.5V @ 250μA
  • Maximum Gate Charge: 2.3nC @ 4.5V
  • Maximum Input Capacitance: 50pF @ 10V
  • Maximum Rds On: 450 mOhm @ 500mA, 4.5V
  • Compliance: Halogen-Free
  • Estimated EOL Date: 2024
