FDN302P

Name: FDN302P
Brand: Fairchild/ON Semiconductor
SKU: 129532
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FDN302P
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 20V 2.4A SSOT3
Datasheet	FDN302P Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	20V
Continuous Drain Current at 25°C	2.4A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	2.5V, 4.5V
Gate-Source Threshold Voltage	1.5V @ 250μA
Max Gate Charge	14nC @ 4.5V
Max Input Capacitance	882pF @ 10V
Maximum Gate-Source Voltage	±12V
Power Dissipation (Max)	500mW (Ta)
Maximum Rds On at Id,Vgs	55 mOhm @ 2.4A, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SuperSOT-3
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	016097-FDN302P
Family Name	FDN302P
Introduction Date	October 30, 2000
ECCN	EAR99
Country of Origin	Israel, Philippines
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Power Management
Quantity per package	3k pcs
Ultra Librarian 3D Model	Ultra Librarian FDN302P CAD Model

Alternative Products

Description

This Fairchild/ON Semiconductor MOSFET is a P-Channel type.

Drain-Source Breakdown Voltage: 20V
Continuous Drain Current: 2.4A @ 25°C
Gate-Source Threshold Voltage: 1.5V @ 250μA
Maximum Gate Charge: 14nC @ 4.5V
Maximum Input Capacitance: 882pF @ 10V
Maximum Rds On: 55 mOhm @ 2.4A, 4.5V
Case/Package: SuperSOT-3
Operating Temperature: -55°C to 150°C
Quantity: 3k pcs per package

Suitable for use in power management applications.
