FDS6575 Real Image FDS6575 Real Image
Same model may have multiple batches, images only for reference.
FDS6575 Real Image FDS6575 Real Image
FDS6575 Real Image FDS6575 Real Image
Same model may have multiple batches, images only for reference.

FDS6575

Part No FDS6575
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 20V 10A 8-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 10A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 74nC @ 4.5V
Max Input Capacitance 4951pF @ 10V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 2.5W (Ta)
Maximum Rds On at Id,Vgs 13 mOhm @ 10A, 4.5V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 016155-FDS6575
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FDS6575 CAD Model

Description

The FDS6575 is a P-Channel MOSFET electronic component manufactured by Fairchild/ON Semiconductor. It is designed for power management and industrial applications.

  • Package: 8-SO
  • Mounting Technology: SMD (SMT)
  • Drain-Source Breakdown Voltage: 20V
  • Continuous Drain Current (25°C): 10A
  • Gate-Source Threshold Voltage: 1.5V @ 250μA
  • Maximum Gate Charge: 74nC @ 4.5V
  • Maximum Input Capacitance: 4951pF @ 10V
