FDU8796 Fairchild/ON Semiconductor FDU8796 real image4159
Same model may have multiple batches, images only for reference.
FDU8796 Fairchild/ON Semiconductor FDU8796 real image4159
FDU8796 Fairchild/ON Semiconductor FDU8796 real image4159
Same model may have multiple batches, images only for reference.

FDU8796

Part No FDU8796
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 25V 35A I-PAK
Datasheet
FDU8796 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 25V
Continuous Drain Current at 25°C 35A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 250μA
Max Gate Charge 52nC @ 10V
Max Input Capacitance 2610pF @ 13V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 88W (Tc)
Maximum Rds On at Id,Vgs 5.7 mOhm @ 35A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package IPAK (TO-251)
Dimension TO-251-3 Short Leads, IPak, TO-251AA
Win Source Part Number 123446-FDU8796
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian FDU8796 CAD Model

Description

The Fairchild/ON Semiconductor FDU8796 is an obsolete N-channel MOSFET designed for discrete semiconductor products.

  • Status: Obsolete
  • Supply and Demand Status: Limited
  • Maximum Power Dissipation: 88W
  • Drain-Source Breakdown Voltage: 25V
  • Maximum Rds On: 5.7 mOhm @ 35A, 10V
  • Package: IPAK (TO-251)
  • Win Source Part Number: 123446-FDU8796
