FQA160N08 Fairchild/ON Semiconductor FQA160N08 Real Image FQA160N08 label picture
Same model may have multiple batches, images only for reference.
FQA160N08 Fairchild/ON Semiconductor FQA160N08 Real Image FQA160N08 label picture
FQA160N08 Fairchild/ON Semiconductor FQA160N08 Real Image FQA160N08 label picture
Same model may have multiple batches, images only for reference.

FQA160N08

Part No FQA160N08
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 80V 160A TO-3P
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 80V
Continuous Drain Current at 25°C 160A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 290nC @ 10V
Max Input Capacitance 7900pF @ 25V
Maximum Gate-Source Voltage ±25V
Power Dissipation (Max) 375W (Tc)
Maximum Rds On at Id,Vgs 7 mOhm @ 80A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-3PN
Dimension TO-3P-3, SC-65-3
Win Source Part Number 1039541-FQA160N08
Popularity Medium
Supply and Demand Status Limited
Quantity per package 450
Ultra Librarian 3D Model Ultra Librarian FQA160N08 CAD Model

Description

The Fairchild/ON Semiconductor FQA160N08 is an N-Channel MOSFET with a drain-source breakdown voltage of 80V and a continuous drain current of 160A @ 25°C.

  • Drain-Source Breakdown Voltage: 80V
  • Continuous Drain Current: 160A @ 25°C
  • Maximum Rds On: 7 mOhm @ 80A, 10V
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate-Source Voltage: ±25V
  • Maximum Gate Charge: 290nC @ 10V
  • Maximum Input Capacitance: 7900pF @ 25V
  • Drive Voltage: 10V
  • Case/Package: TO-3PN, TO-3P-3, SC-65-3
  • Use: Discrete Semiconductor Products
