FDV304P Fairchild/ON Semiconductor FDV304P Real Image FDV304P label picture 3 FDV304P label picture 3 FDV304P real image FDV304P real image 2 FDV304P Real Image1 FDV304P Real Image2 FDV304P Real Image3 FDV304P Real Image4 FDV304P Real Image5 FDV304P Real Image6 FDV304P Real Image7
Same model may have multiple batches, images only for reference.
FDV304P Fairchild/ON Semiconductor FDV304P Real Image FDV304P label picture 3 FDV304P label picture 3 FDV304P real image FDV304P real image 2 FDV304P Real Image1 FDV304P Real Image2 FDV304P Real Image3 FDV304P Real Image4 FDV304P Real Image5 FDV304P Real Image6 FDV304P Real Image7
FDV304P Fairchild/ON Semiconductor FDV304P Real Image FDV304P label picture 3 FDV304P label picture 3 FDV304P real image FDV304P real image 2 FDV304P Real Image1 FDV304P Real Image2 FDV304P Real Image3 FDV304P Real Image4 FDV304P Real Image5 FDV304P Real Image6 FDV304P Real Image7
Same model may have multiple batches, images only for reference.

FDV304P

Part No FDV304P
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 25V 460MA SOT-23
Datasheet
FDV304P Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 25V
Continuous Drain Current at 25°C 460mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.7V, 4.5V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 1.5nC @ 4.5V
Max Input Capacitance 63pF @ 10V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 350mW (Ta)
Maximum Rds On at Id,Vgs 1.1 Ohm @ 500mA, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 016221-FDV304P
Family Name FDV304P
Introduction Date September 29, 1997
ECCN EAR99
Country of Origin China, Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Consumer Electronics, Communications & Networking, Portable Devices, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian FDV304P CAD Model

Description

The Fairchild/ON Semiconductor FDV304P is a P-Channel MOSFET designed for use in power management, consumer electronics, communications and networking, portable devices, and computers and computer peripherals.

  • Drain-Source Breakdown Voltage: 25V
  • Continuous Drain Current: 460mA @ 25°C
  • Rds On (max): 1.1 Ohm @ 500mA, 4.5V
  • Package: SOT-23
  • Operating Temperature: -55°C to 150°C (TJ)
  • Power Dissipation (max): 350mW (Ta)
  • Gate-Source Voltage (max): ±8V
  • Reel Quantity: 3,000
