FDW2520C

Name: FDW2520C
Brand: Fairchild/ON Semiconductor
SKU: 130136
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	FDW2520C
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N/P-CH 20V 6A/4.4A 8TSSOP
Datasheet	FDW2520C Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Obsolete(EOL)
FET Type	N and P-Channel
FET Feature	Logic Level Gate
Drain-Source Breakdown Voltage	20V
Continuous Drain Current at 25°C	6A, 4.4A
Maximum Rds On at Id,Vgs	18 mOhm @ 6A, 4.5V
Gate-Source Threshold Voltage	1.5V @ 250μA
Max Gate Charge	20nC @ 4.5V
Max Input Capacitance	1325pF @ 10V
Maximum Power Dissipation	600mW
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-TSSOP
Win Source Part Number	30136-FDW2520C
Family Name	FDW2520C
Introduction Date	December 08, 2000
ECCN	EAR99
Halogen Free	Compliant
Estimated EOL Date	Obsolete
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian FDW2520C CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor FDW2520C is a logic level gate N and P-channel FET that is used for discrete semiconductor applications.

Maximum Power Dissipation: 600mW
Continuous Drain Current (25°C): 6A
Gate-Source Threshold Voltage: 1.5V @ 250μA
Maximum Gate Charge: 20nC @ 4.5V
Package: 8-TSSOP
Mounting: Printed Circuit Board
Operating Temperature: -55°C to 150°C
Status: Obsolete (EOL)
Popularity: High
Supply/Demand: Balanced
