FEBFAN6100QMPX_CH07U15A Fairchild/ON Semiconductor
Same model may have multiple batches, images only for reference.

FEBFAN6100QMPX_CH07U15A

Part No FEBFAN6100QMPX_CH07U15A
Manufacturer Fairchild/ON Semiconductor
Catalog Evaluation Boards - DC/DC & AC/DC (Off - Line)SMPS
Description EVAL BOARD FOR FAN6100 / FAN501A/FAN6100Q Voltage Supervisory 5VDC/9VDC/12VDC Output Evaluation Board
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Fairchild/ON Semiconductor
Main Purpose AC/DC, Primary and Secondary Side
Outputs and Type 1, Isolated
Power - Output 15W
Voltage - Output 5V, 9V or 12V
Output Current 2A
Voltage - Input 90 ~ 264 VAC
Regulator Topology Flyback
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part FAN501A, FAN6100Q
Win Source Part Number 774423-FEBFAN6100QMPX_CH07U15A
Popularity Medium
Supply and Demand Status Balance
Family Name FEBFAN6100QMPX_CH07U15A
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian FEBFAN6100QMPX_CH07U15A CAD Model

Description

The FEBFAN6100QMPX_CH07U15A is a fully populated development board manufactured by Fairchild/ON Semiconductor.

  • Topology: Flyback regulator
  • Output Voltage: 5V, 9V or 12V
  • Input Voltage: 90 ~ 264 VAC
  • Application: AC/DC primary and secondary side
  • Output Power: 15W
  • Output Current: 2A
  • ICs/Parts: FAN501A and FAN6100Q
  • Board Contents: Board(s)
  • Family: FEBFAN6100QMPX_CH07U15A
  • Isolation: Isolated
  • Output: One
  • Category: Development boards, kits, programmers
  • ECCN: EAR99
  • Estimated EOL Date: Obsolete/end of life
  • Supply and Demand Status: Balanced
