FJP13007H1TU Real Image FJP13007H1TU real image
Same model may have multiple batches, images only for reference.
FJP13007H1TU Real Image FJP13007H1TU real image
FJP13007H1TU Real Image FJP13007H1TU real image
Same model may have multiple batches, images only for reference.

FJP13007H1TU

Part No FJP13007H1TU
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS NPN 400V 8A TO-220
Datasheet
FJP13007H1TU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Transistor Polarity NPN
Maximum Current Collector 8A
VCEO Maximum Collector-Emitter Breakdown Voltage 400V
Max Vce (sat) 3V @ 2A, 8A
Typical Gain (hFE) (Min) 15 @ 2A, 5V
Maximum Power Dissipation 80W
Frequency - Transition 4MHz
Temperature Range - Operating 150°C (TJ)
Mounting Through Hole
Case / Package TO-220-3
Win Source Part Number 067229-FJP13007H1TU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian FJP13007H1TU CAD Model

Description

The Fairchild/ON Semiconductor FJP13007H1TU is a NPN transistor electronic component.

  • Case/Package: TO-220-3
  • Frequency-Transition: 4MHz
  • Maximum Current Collector: 8A
  • VCEO Maximum Collector-Emitter Breakdown Voltage: 400V
  • Max Vce (sat): 3V @ 2A, 8A
  • Typical Gain (hFE) (Min): 15 @ 2A, 5V
  • Maximum Power Dissipation: 80W
  • Operating Temperature: 150°C (TJ)
