FQD16N25CTM Real Image FQD16N25CTM Real Image1 FQD16N25CTM Real Image2 FQD16N25CTM Real Image3 FQD16N25CTM Real Image4
Same model may have multiple batches, images only for reference.
FQD16N25CTM Real Image FQD16N25CTM Real Image1 FQD16N25CTM Real Image2 FQD16N25CTM Real Image3 FQD16N25CTM Real Image4
FQD16N25CTM Real Image FQD16N25CTM Real Image1 FQD16N25CTM Real Image2 FQD16N25CTM Real Image3 FQD16N25CTM Real Image4
Same model may have multiple batches, images only for reference.

FQD16N25CTM

Part No FQD16N25CTM
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 250V 16A D-PAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 250V
Continuous Drain Current at 25°C 16A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 53.5nC @ 10V
Max Input Capacitance 1080pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 160W (Tc)
Maximum Rds On at Id,Vgs 270 mOhm @ 8A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 126237-FQD16N25CTM
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FQD16N25CTM CAD Model

Description

The Fairchild/ON Semiconductor FQD16N25CTM is a N-Channel MOSFET with the following specifications:

  • Drain-Source Breakdown Voltage: 250V
  • Continuous Drain Current (Tc): 16A
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate-Source Voltage: ±30V
  • Package: D-Pak (TO-252-3, DPak (2 Leads + Tab), SC-63)
  • Maximum Rds On: 270 mOhm @ 8A, 10V
  • Power Dissipation (Max): 160W (Tc)
  • Mounting: SMD (SMT)
  • Packaging: Reel - TR
