FSL126HR Fairchild/ON Semiconductor FSL126HR Real Image FSL126HR real image FSL126HR real image 2
Same model may have multiple batches, images only for reference.
FSL126HR Fairchild/ON Semiconductor FSL126HR Real Image FSL126HR real image FSL126HR real image 2
FSL126HR Fairchild/ON Semiconductor FSL126HR Real Image FSL126HR real image FSL126HR real image 2
Same model may have multiple batches, images only for reference.

FSL126HR

Part No FSL126HR
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - AC DC Converters, Offline Switchers
Description AC DC Converters, Offline Switchers / IC FPS SWITCH PWM/SENSEFET 8DIP
Datasheet
FSL126HR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 650V
Topology Flyback
Voltage - Start Up 12V
Supply Voltage - Operating 8 V to 26 V
Duty Cycle 77%
Frequency - Switching 100kHz
Power (Watts) 21W
Fault Protection Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit
Control Operating Temperature -40°C to 105°C (TA)
Case / Package 8-DIP
Mounting Through Hole
Win Source Part Number 204343-FSL126HR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 3k pcs
Family Name FSL126HR
Introduction Date March 28, 2011
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian FSL126HR CAD Model

Description

The FSL126HR is a Flyback topology integrated circuit manufactured by Fairchild/ON Semiconductor.

  • Package: 8-DIP
  • Power Output: 21W
  • Output Isolation: Yes
  • Voltage-Breakdown: 650V
  • Internal Switch: Yes
  • Frequency-Switching: 100kHz
  • Duty Cycle: 77%
  • Fault Protection: Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit
  • Supply Voltage: 8V to 26V
  • Operating Temperature: -40°C to 105°C (TA)
  • Supply and Demand Status: Balanced
