FSUSB42MUX Fairchild/ON Semiconductor FSUSB42MUX Real Image FSUSB42MUX real image FSUSB42MUX real image4266 FSUSB42MUX real image4267 FSUSB42MUX real image4268 FSUSB42MUX real image4269 FSUSB42MUX Real Image1 FSUSB42MUX Real Image2 FSUSB42MUX Real Image3
Same model may have multiple batches, images only for reference.
FSUSB42MUX Fairchild/ON Semiconductor FSUSB42MUX Real Image FSUSB42MUX real image FSUSB42MUX real image4266 FSUSB42MUX real image4267 FSUSB42MUX real image4268 FSUSB42MUX real image4269 FSUSB42MUX Real Image1 FSUSB42MUX Real Image2 FSUSB42MUX Real Image3
FSUSB42MUX Fairchild/ON Semiconductor FSUSB42MUX Real Image FSUSB42MUX real image FSUSB42MUX real image4266 FSUSB42MUX real image4267 FSUSB42MUX real image4268 FSUSB42MUX real image4269 FSUSB42MUX Real Image1 FSUSB42MUX Real Image2 FSUSB42MUX Real Image3
Same model may have multiple batches, images only for reference.

FSUSB42MUX

Part No FSUSB42MUX
Manufacturer Fairchild/ON Semiconductor
Catalog Interface - Analog Switches - Special Purpose
Description IC USB SWITCH DPDT 10MSOP
Datasheet
FSUSB42MUX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Applications USB
Switch Circuit DPDT
Number of Channels 1
Max On Resistance 6.5 Ohm
Single Supply Voltage (V+) 2.4 V to 4.4 V
-3db Bandwidth 720MHz
Features Break-Before-Make, USB 2.0
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 10-MSOP
Win Source Part Number 092463-FSUSB42MUX
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name FSUSB42
Introduction Date June 01, 2007
ECCN EAR99
Country of Origin China, United States of America
Halogen Free Compliant
Estimated EOL Date 2024
Quantity per package 4k pcs
Ultra Librarian 3D Model Ultra Librarian FSUSB42MUX CAD Model

Description

The FSUSB42MUX is a DPDT USB 2.0 multiplexer/demultiplexer circuit IC manufactured by Fairchild/ON Semiconductor.

  • -3dB Bandwidth: 720MHz
  • Application: USB applications
  • Package: 10-MSOP
  • Single Supply Voltage: 2.4V to 4.4V
  • Popularity: High
  • Supply and Demand Status: Balanced
