FYD0504SATM Fairchild/ON Semiconductor FYD0504SATM label picture FYD0504SATM real image
Same model may have multiple batches, images only for reference.
FYD0504SATM Fairchild/ON Semiconductor FYD0504SATM label picture FYD0504SATM real image
FYD0504SATM Fairchild/ON Semiconductor FYD0504SATM label picture FYD0504SATM real image
Same model may have multiple batches, images only for reference.

FYD0504SATM

Part No FYD0504SATM
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 5A DPAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 5A
Voltage - Forward (Vf) (Max) @ If 550mV @ 5A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1mA @ 40V
Mounting SMD (SMT)
Case / Package D-Pak
Operating Temperature - Junction -65°C to 150°C
Win Source Part Number 001348-FYD0504SATM
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FYD0504SATM CAD Model

Description

The Fairchild/ON Semiconductor FYD0504SATM is a Schottky diode that comes with a fast recovery of 200mA (Io).

  • Maximum DC Reverse Voltage: 40V
  • Average Rectified Current: 5A
  • Forward Voltage at Max If: 550mV @ 5A
  • Reverse Leakage Current at Vr: 1mA @ 40V
  • Capacitance at Vr, F: None
  • Operating Temperature: -65°C to 150°C
  • Category: Discrete Semiconductor Product - Active
  • Package: D-Pak
  • Quantity: 2,500
