KSC5026MOS Real Image KSC5026MOS Real Image
Same model may have multiple batches, images only for reference.
KSC5026MOS Real Image KSC5026MOS Real Image
KSC5026MOS Real Image KSC5026MOS Real Image
Same model may have multiple batches, images only for reference.

KSC5026MOS

Part No KSC5026MOS
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS NPN 800V 1.5A TO-126
Datasheet
KSC5026MOS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Bulk
Status Active
Transistor Polarity NPN
Maximum Current Collector 1.5A
VCEO Maximum Collector-Emitter Breakdown Voltage 800V
Max Vce (sat) 2V @ 150mA, 750mA
Collector Cut-off Current(Max) 10μA (ICBO)
Typical Gain (hFE) (Min) 20 @ 100mA, 5V
Maximum Power Dissipation 20W
Frequency - Transition 15MHz
Temperature Range - Operating 150°C (TJ)
Mounting Through Hole
Case / Package TO-126-3
Win Source Part Number 070501-KSC5026MOS
Popularity Medium
Supply and Demand Status Limited
Quantity per package 2k pcs
Ultra Librarian 3D Model Ultra Librarian KSC5026MOS CAD Model

Description

The KSC5026MOS is a Fairchild/ON Semiconductor NPN transistor that has a maximum current collector of 1.5A and a VCEO maximum collector-emitter breakdown voltage of 800V.

  • Maximum Current Collector: 1.5A
  • VCEO Maximum Collector-Emitter Breakdown Voltage: 800V
  • Package: TO-126-3
  • Maximum Power Dissipation: 20W
