LM7824CT Real Image LM7824CT real image
Same model may have multiple batches, images only for reference.
LM7824CT Real Image LM7824CT real image
LM7824CT Real Image LM7824CT real image
Same model may have multiple batches, images only for reference.

LM7824CT

Part No LM7824CT
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 24V 1A TO220-3
Datasheet
LM7824CT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 40V
Nominal Output Voltage (Min/Fixed) 24V
Dropout Voltage-Max 2V @ 1A (Typ)
Output Current 1A
Operating Supply Current 8mA
PSRR 67dB (120Hz)
Control Protection Features Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 24V
Voltage - Dropout (Typical) 2V @ 1A
Mounting Through Hole
Case / Package TO-220-3
Win Source Part Number 128937-LM7824CT
Popularity Medium
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian LM7824CT CAD Model

Description

The Fairchild/ON Semiconductor LM7824CT is an active component in the integrated circuits category.

It is a positive fixed voltage regulator with an output voltage of 24V and an output current of 1A.

  • Regulator Topology: fixed
  • Dropout Voltage: 2V at 1A
  • Case/Package: TO-220-3
  • Temperature Range: -40°C to 125°C

It is a balanced supply and demand component with medium popularity.

It is often used in power supplies, industrial control systems, and other applications that require a stable 24V output voltage.
