MJE172STU Fairchild/ON Semiconductor MJE172STU real image MJE172STU label picture
Same model may have multiple batches, images only for reference.
MJE172STU Fairchild/ON Semiconductor MJE172STU real image MJE172STU label picture
MJE172STU Fairchild/ON Semiconductor MJE172STU real image MJE172STU label picture
Same model may have multiple batches, images only for reference.

MJE172STU

Part No MJE172STU
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS PNP 80V 3A TO-126
Datasheet
MJE172STU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Transistor Polarity PNP
Maximum Current Collector 3A
VCEO Maximum Collector-Emitter Breakdown Voltage 80V
Max Vce (sat) 1.7V @ 600mA, 3A
Collector Cut-off Current(Max) 100nA (ICBO)
Typical Gain (hFE) (Min) 50 @ 100mA, 1V
Maximum Power Dissipation 1.5W
Frequency - Transition 50MHz
Temperature Range - Operating 150°C (TJ)
Mounting Through Hole
Case / Package TO-126
Win Source Part Number 112110-MJE172STU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MJE172
Introduction Date June 08, 2001
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete
Quantity per package 1,920
Ultra Librarian 3D Model Ultra Librarian MJE172STU CAD Model

Description

The MJE172 is a PNP bipolar junction transistor manufactured by Fairchild/ON Semiconductor.

  • Maximum Collector-Emitter Breakdown Voltage: 80V
  • Maximum Current Collector: 3A
  • Frequency Transition: 50MHz
  • Typical Gain: 50 @ 100mA and 1V
  • Package: TO-126
  • Mounting: Through a hole
  • Maximum Power Dissipation: 1.5W
  • Temperature Range: 150°C (TJ)
