MMBTA42

Name: MMBTA42
Brand: Fairchild/ON Semiconductor
SKU: 235502
Availability: InStock
Rating: 4.91 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MMBTA42
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors (BJT) - Single
Description	Trans GP BJT NPN 300V 0.5A 240mW 3-Pin SOT-23 T/R / TRANS NPN 300V 0.5A SOT-23
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Transistor Polarity	NPN
Maximum Current Collector	500mA
VCEO Maximum Collector-Emitter Breakdown Voltage	300V
Max Vce (sat)	500mV @ 2mA, 20mA
Collector Cut-off Current(Max)	100nA (ICBO)
Typical Gain (hFE) (Min)	40 @ 30mA, 10V
Maximum Power Dissipation	240mW
Frequency - Transition	50MHz
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3
Win Source Part Number	084232-MMBTA42
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial, Power Management
Quantity per package	3k pcs
Family Name	MMBTA42
Introduction Date	July 06, 2000
ECCN	EAR99
Country of Origin	China, Philippines
Halogen Free	Compliant
Estimated EOL Date	Obsolete / End of life
Package	Tape & Reel (TR)
Product Status	Active
Transistor Type	NPN
Current - Collector (Ic) (Max)	100mA
Voltage - Collector Emitter Breakdown (Max)	300V
Vce Saturation (Max) @ Ib, Ic	200mV @ 2mA, 20mA
Current - Collector Cutoff (Max)	0.25µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	60 @ 1mA, 10V
Power - Max	350mW
Operating Temperature	-65°C ~ 150°C (TJ)
Grade	-
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Supplier Device Package	SOT-23
Ultra Librarian 3D Model	Ultra Librarian MMBTA42 CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor MMBTA42 is an NPN transistor that is commonly used in discrete semiconductor products.

Maximum Collector-Emitter Breakdown Voltage: 300V
Maximum Current Collector: 500mA
Typical Gain: 40 @ 30mA and 10V
Package: SOT-23-3
Mounting: SMD (SMT) technology
Maximum Power Dissipation: 240mW
Operating Temperature Range: -55°C to 150°C (TJ)
Supply and Demand: sufficient
Applications: industrial and power management
