NC7SZ04L6X Real Image NC7SZ04L6X Real Image1 NC7SZ04L6X Real Image2
Same model may have multiple batches, images only for reference.
NC7SZ04L6X Real Image NC7SZ04L6X Real Image1 NC7SZ04L6X Real Image2
NC7SZ04L6X Real Image NC7SZ04L6X Real Image1 NC7SZ04L6X Real Image2
Same model may have multiple batches, images only for reference.

NC7SZ04L6X

Part No NC7SZ04L6X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC INVERTER UHS 6-MICROPAK
Datasheet
NC7SZ04L6X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 1
Number of Inputs 1
Supply Voltage - Operating 1.65 V to 5.5 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 32mA, 32mA
Max Propagation Delay @ V, Max CL 4.3ns @ 5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 6-MicroPak
Dimension 6-UFDFN
Win Source Part Number 024802-NC7SZ04L6X
Popularity Medium
Supply and Demand Status Sufficient
Quantity per package 5k pcs
Ultra Librarian 3D Model Ultra Librarian NC7SZ04L6X CAD Model

Description

The Fairchild/ON Semiconductor NC7SZ04L6X is a single-circuit inverter with SMD (SMT) mounting and a 6-MicroPak case.

  • Maximum propagation delay: 4.3ns @ 5V and 50pF
  • Quiescent current: 2μA
  • Logic type: inverter
  • Inputs: one
  • Current output high/low: 32mA
  • Operating temperature range: -40°C to 85°C
  • Supply voltage: 1.65 V to 5.5 V
