NC7SZ05P5X Real Image NC7SZ05P5X Real Image
Same model may have multiple batches, images only for reference.
NC7SZ05P5X Real Image NC7SZ05P5X Real Image
NC7SZ05P5X Real Image NC7SZ05P5X Real Image
Same model may have multiple batches, images only for reference.

NC7SZ05P5X

Part No NC7SZ05P5X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC INVERTER UHS OPEN DRN SC70-5
Datasheet
NC7SZ05P5X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 1
Number of Inputs 1
Features Open Drain
Supply Voltage - Operating 1.65 V to 5.5 V
Current - Quiescent (Max) 2μA
Current - Output High, Low -, 32mA
Max Propagation Delay @ V, Max CL 4.3ns @ 5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SC-70-5
Dimension 5-TSSOP, SC-70-5, SOT-353
Win Source Part Number 024806-NC7SZ05P5X
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7SZ05P5X CAD Model

Description

The Fairchild/ON Semiconductor NC7SZ05P5X is an inverter IC from Fairchild/ON Semiconductor.

  • Feature: Open Drain
  • Max Propagation Delay: 4.3ns @ 5V and 50pF
  • Quiescent Current: 2μA
  • Supply Voltage: 1.65 V to 5.5 V
  • Package / Case: SC-70-5
  • Mounting Type: Surface Mounted
  • Temperature Rating: -40°C to 85°C
  • Application: Digital Circuits
