NDT3055 Real Image NDT3055 real image4028 NDT3055 Real Image1 NDT3055 Real Image2
Same model may have multiple batches, images only for reference.
NDT3055 Real Image NDT3055 real image4028 NDT3055 Real Image1 NDT3055 Real Image2
NDT3055 Real Image NDT3055 real image4028 NDT3055 Real Image1 NDT3055 Real Image2
Same model may have multiple batches, images only for reference.

NDT3055

Part No NDT3055
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 4A SOT-223-4
Datasheet
NDT3055 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 4A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 15nC @ 10V
Max Input Capacitance 250pF @ 30V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3W (Ta)
Maximum Rds On at Id,Vgs 100 mOhm @ 4A, 10V
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223-4
Dimension TO-261-4, TO-261AA
Win Source Part Number 025179-NDT3055
Popularity Medium
Supply and Demand Status Balance
Quantity per package 4k pcs
Ultra Librarian 3D Model Ultra Librarian NDT3055 CAD Model

Description

The Fairchild/ON Semiconductor 025179-NDT3055 is an N-Channel MOSFET with a maximum power dissipation of 3W (Ta).

  • Mounting Type: SMD (SMT)
  • Power Dissipation: 3W (Ta)
  • Drive Voltage: 10V
  • Drain-Source Breakdown Voltage: 60V
  • Maximum Rds On @ Id, Vgs: 100 mOhm @ 4A, 10V
  • Win Source Part Number: 025179-NDT3055
  • Popularity: Medium popularity electronic component with a balanced supply and demand status
