MC68HC705J1ACPE Freescale Semiconductor - NXP MC68HC705J1ACPE Real Image MC68HC705J1ACPE real image
Same model may have multiple batches, images only for reference.
MC68HC705J1ACPE Freescale Semiconductor - NXP MC68HC705J1ACPE Real Image MC68HC705J1ACPE real image
MC68HC705J1ACPE Freescale Semiconductor - NXP MC68HC705J1ACPE Real Image MC68HC705J1ACPE real image
Same model may have multiple batches, images only for reference.

MC68HC705J1ACPE

Part No MC68HC705J1ACPE
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microcontrollers
Description IC MCU 8BIT 1.2KB OTP 20DIP
Datasheet
MC68HC705J1ACPE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tube/Rail
Status Obsolete(EOL)
Core Processor HC05
Part Core Size 8-Bit
Speed(Frequency) 4MHz
Number of I/O 14
Program Memory Size 1.2KB (1.2K x 8)
Program Memory Type OTP
Data RAM Size 64 x 8
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 20-DIP
Win Source Part Number 086047-MC68HC705J1ACPE
Family Name MC68HC705J1A
Introduction Date April 07, 2005
ECCN EAR99
Country of Origin Philippines
Halogen Free Not Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MC68HC705J1ACPE CAD Model

Description

The NXP MC68HC705J1ACPE is an integrated circuit that belongs to the HC05 core processor family.

  • Manufacturer: NXP
  • Core Processor Family: HC05
  • Number of I/O pins: 14
  • Program Memory Size: 1.2KB
  • Program Memory Type: OTP
  • Data Converters: Not featured
  • Package: 20-DIP
  • Speed (Frequency): 4MHz
  • Operating Temperature Range: from -40°C to 85°C (TA)
  • Supply Voltage Range: 3V to 5.5V
  • Part Core Size: 8-bit
  • Data RAM Size: 64 x 8
  • Applications: automotive electronics, industrial control systems, and consumer electronics
