MPXC2011DT1

Part No MPXC2011DT1
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description PEIZORESISTIVE SENSOR, DIFFERENT / Pressure Sensor 1.45PSI (10kPa) Differential 0 mV ~ 25 mV (10V) 4-SSIP Module
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Pressure Sensors, Transducers
Manufacturer Freescale Semiconductor
Packaging Bulk
Applications Board Mount
Pressure Type Differential
Operating Pressure 1.45PSI (10kPa)
Output Type Wheatstone Bridge
Output 0 mV ~ 25 mV (10V)
Voltage - Supply 3V ~ 10V
Port Style Barbless
Features Temperature Compensated
Termination Style PC Pin
Maximum Pressure 10.88PSI (75kPa)
Temperature Range - Operating 15°C ~ 40°C
Case / Package 4-SSIP Module
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 2156-MPXC2011DT1,FREFREMPXC2011DT1
Standard Package 1
Win Source Part Number 1336602-MPXC2011DT1
Ultra Librarian 3D Model Ultra Librarian MPXC2011DT1 CAD Model

Description

The Freescale Semiconductor MPXC2011DT1 is a differential pressure sensor that is temperature compensated.

  • Termination Style: PC Pin
  • Mounting Type: Board Mount
  • Output Type: Wheatstone Bridge
  • Output: 0 mV to 25 mV @ 10V
  • Operating Pressure: 1.45PSI (10kPa)
  • Maximum Pressure: 10.88PSI (75kPa)
  • Voltage Supply: 3V to 10V
  • Temperature Range: 15°C to 40°C
  • Package: 4-SSIP Module
  • ECCN: EAR99
  • HTSUS: 8542.39.0001
  • Other Part Numbers: 2156-MPXC2011DT1, FREFREMPXC2011DT1
