The TG23-1505N1TR is a LAN Isolation Transformer manufactured by Halo Electronics Inc. This transformer is designed for Ethernet and networking applications requiring electrical isolation and common-mode noise reduction. It meets or exceeds IEEE 802.3 standards, ensuring compatibility and reliability. The 'TR' suffix typically indicates that the component is supplied in tape and reel packaging for automated assembly processes.

Applications

• Ethernet interfaces
• Network interface cards (NICs)
• Routers
• Switches
• Embedded networking systems

Features

• Electrical isolation
• Common-mode noise reduction
• IEEE 802.3 compliance
• Surface mount package
• Tape and reel packaging (TR suffix)
• RoHS compliant

Benefits

• Protection against voltage surges and transients
• Improved signal integrity in noisy environments
• Reliable data transmission
• Easy integration into automated assembly lines
• Compliance with industry standards
• Environmentally friendly

Additional Details

The TG23-1505N1TR LAN isolation transformer offers electrical isolation and common-mode noise reduction for Ethernet and networking applications. Meeting IEEE 802.3 standards ensures interoperability. Electrical specifications typically include isolation voltage, insertion loss, return loss, and common-mode rejection ratio. The tape and reel packaging facilitates automated pick-and-place assembly, streamlining manufacturing. The surface mount package makes it suitable for compact designs. RoHS compliance indicates adherence to environmental regulations. Operating temperature ranges are suitable for typical networking environments. This part is designed for reflow soldering assembly.
