AUIRFS4310ZTRL Infineon Technologies AUIRFS4310ZTRL label picture AUIRFS4310ZTRL label picture
Same model may have multiple batches, images only for reference.
AUIRFS4310ZTRL Infineon Technologies AUIRFS4310ZTRL label picture AUIRFS4310ZTRL label picture
AUIRFS4310ZTRL Infineon Technologies AUIRFS4310ZTRL label picture AUIRFS4310ZTRL label picture
Same model may have multiple batches, images only for reference.

AUIRFS4310ZTRL

Part No AUIRFS4310ZTRL
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 120A D2PAK
Datasheet
AUIRFS4310ZTRL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 120A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 150μA
Max Gate Charge 170nC @ 10V
Max Input Capacitance 6860pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 250W (Tc)
Maximum Rds On at Id,Vgs 6 mOhm @ 75A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 127449-AUIRFS4310ZTRL
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name AUIRFS4310Z
Introduction Date August 22, 2011
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian AUIRFS4310ZTRL CAD Model

Description

AUIRFS4310ZTRL - N-Channel MOSFET for Power Applications

The AUIRFS4310ZTRL is a high-performance MOSFET tailored for applications where power efficiency and reliability are crucial. It supports engineers seeking top-tier power management components.

  • Voltage Endurance: 100V
  • Drain Current Capacity: 140A
  • Efficient Power Dissipation
  • Resilient to Temperature Variations

Applications

  • Power Inverters
  • Solar Panel Controllers
  • Electric Vehicle Charging Stations
  • Automation Systems

Benefits

  • High energy efficiency
  • Reduction in operational costs
  • High reliability under stress
  • Extensive application range
