BSC014N06NS Infineon Technologies BSC014N06NS real image2711 BSC014N06NS Real Image1 BSC014N06NS Real Image2 BSC014N06NS Real Image3 BSC014N06NS Real Image4 BSC014N06NS Real Image5 BSC014N06NS Real Image6
Same model may have multiple batches, images only for reference.
BSC014N06NS Infineon Technologies BSC014N06NS real image2711 BSC014N06NS Real Image1 BSC014N06NS Real Image2 BSC014N06NS Real Image3 BSC014N06NS Real Image4 BSC014N06NS Real Image5 BSC014N06NS Real Image6
BSC014N06NS Infineon Technologies BSC014N06NS real image2711 BSC014N06NS Real Image1 BSC014N06NS Real Image2 BSC014N06NS Real Image3 BSC014N06NS Real Image4 BSC014N06NS Real Image5 BSC014N06NS Real Image6
Same model may have multiple batches, images only for reference.

BSC014N06NS

Part No BSC014N06NS
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 30A TDSON-8
Datasheet
BSC014N06NS Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 30A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Gate-Source Threshold Voltage 2.8V @ 120μA
Max Gate Charge 89nC @ 10V
Max Input Capacitance 6500pF @ 30V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta), 156W (Tc)
Maximum Rds On at Id,Vgs 1.45 mOhm @ 50A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-TDSON-8
Dimension 8-PowerTDFN
Win Source Part Number 142021-BSC014N06NS
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BSC014N06NS CAD Model

Description

Product Overview

The BSC014N06NS is a robust N-channel MOSFET that provides excellent performance in high-voltage applications. It is engineered to support substantial loads while ensuring low energy consumption.

Applications

  • HVAC Systems
  • Power Distribution Units
  • Electric Vehicular Components

Features and Benefits

  • High Voltage Tolerance: Suitable for applications involving significant power demands.
  • Energy-Saving Design: Reduces power waste, enhancing overall system efficiency.
  • Reliable Performance: Designed to handle harsh environmental conditions.

Additional Details

With its outstanding voltage tolerance and energy efficiency, the BSC014N06NS is an ideal component for engineers focused on creating sustainable, high-performance solutions.
