BSC032NE2LSATMA1 Infineon Technologies BSC032NE2LSATMA1 Real Image
Same model may have multiple batches, images only for reference.
BSC032NE2LSATMA1 Infineon Technologies BSC032NE2LSATMA1 Real Image
BSC032NE2LSATMA1 Infineon Technologies BSC032NE2LSATMA1 Real Image
Same model may have multiple batches, images only for reference.

BSC032NE2LSATMA1

Part No BSC032NE2LSATMA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 25V 22A TDSON-8
Datasheet
BSC032NE2LSATMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 25V
Continuous Drain Current at 25°C 22A (Ta), 84A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2V @ 250μA
Max Gate Charge 16nC @ 10V
Max Input Capacitance 1200pF @ 12V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.8W (Ta), 78W (Tc)
Maximum Rds On at Id,Vgs 3.2 mOhm @ 30A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-TDSON-8
Dimension 8-PowerTDFN
Win Source Part Number 130965-BSC032NE2LSATMA1
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BSC032NE2LSATMA1 CAD Model

Description

BSC032NE2LSATMA1

The versatile BSC032NE2LSATMA1 MOSFET is suitable for a variety of applications, designed to provide smooth operation with its advanced technology.

  • Voltage Rating: High threshold
  • Current Rating: Optimized to reduce power wastage
  • Compact and Durable Design

Applications:

  • High-Speed Switching
  • Lighting Controls
  • Embedded Systems

Features and Benefits:

  • Advanced Junction Technology for optimal performance
  • Thermal Stability ensures consistent operation
  • Cost-effective with long service life
