Same model may have multiple batches, images only for reference.

BSS670S2L

Name: BSS670S2L
Brand: Infineon Technologies
SKU: 572255
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	BSS670S2L
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 55V 540MA SOT23-3 / N-Channel 55 V 540mA (Ta) 360mW (Ta) Surface Mount PG-SOT23
Datasheet	BSS670S2L Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr	Infineon Technologies
Series	OptiMOS™
Package	Tape & Reel (TR)Cut Tape (CT)
Product Status	Obsolete
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	55 V
Current - Continuous Drain (Id) @ 25°C	540mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	650mOhm @ 270mA, 10V
Vgs(th) (Max) @ Id	2V @ 2.7µA
Gate Charge (Qg) (Max) @ Vgs	2.26 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	75 pF @ 25 V
Power Dissipation (Max)	360mW (Ta)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PG-SOT23
Package / Case	TO-236-3, SC-59, SOT-23-3
Standard Package	3,000 pcs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.21.0095
Win Source Part Number	572255-BSS670S2L
Ultra Librarian 3D Model	Ultra Librarian BSS670S2L CAD Model

Alternative Products

Description

The 572255-BSS670S2L is an N-Channel MOSFET transistor from Infineon Technologies.

Series: OptiMOS™
Drain to Source Voltage: 55V
Continuous Drain Current: 540mA
On-Resistance: 650mOhm @ 270mA, 10V
Gate Charge: 2.26 nC @ 10V
Package: TO-236-3, SC-59, SOT-23-3
Temperature Range: -55°C to 150°C
