The BSZ025N04LS is a N-Channel enhancement mode MOSFET from Infineon Technologies, designed for high-efficiency power conversion and motor control applications. This MOSFET leverages advanced trench technology to achieve very low on-resistance and superior switching performance.

Applications

• Synchronous rectification in DC-DC converters
• Motor control
• Battery management systems
• Load switching
• Power supplies

Features

• N-Channel Enhancement Mode MOSFET
• Low on-resistance (RDS(on))
• Logic level gate drive
• Fast switching speed
• Avalanche rated

Benefits

• High efficiency in power conversion circuits
• Reduced power dissipation
• Simplified gate drive circuitry
• Minimal switching losses
• Robust performance in demanding applications

Additional Details

The BSZ025N04LS is typically packaged in a SOT-223 package for surface mount assembly and effective thermal management. Key specifications include a drain-source voltage (VDS) of 40V, a continuous drain current (ID) of approximately 28A, and a typical on-resistance (RDS(on)) of 2.5 mΩ at VGS = 10V. The logic-level gate drive ensures that the MOSFET can be easily driven by microcontrollers and other low-voltage logic devices. Its fast switching characteristics make it suitable for high-frequency applications. The avalanche rating provides additional robustness, protecting the device from voltage spikes. This MOSFET is also RoHS compliant, ensuring it meets environmental standards. It is optimized for synchronous rectification, contributing to higher efficiency in DC-DC converters.
