BSZ105N04NS G Infineon Technologies BSZ105N04NS G Real Image
Same model may have multiple batches, images only for reference.
BSZ105N04NS G Infineon Technologies BSZ105N04NS G Real Image
BSZ105N04NS G Infineon Technologies BSZ105N04NS G Real Image
Same model may have multiple batches, images only for reference.

BSZ105N04NS G

Part No BSZ105N04NS G
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 40A TSDSON-8
Datasheet
BSZ105N04NS G Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Series OptiMOS
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 40V
Current - Continuous Drain (Id) @ 25°C 11A (Ta), 40A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Vgs(th) (Maximum) @ Id 4V @ 14μA
Gate Charge (Qg) (Maximum) @ Vgs 17nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 1300pF @ 20V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 2.1W (Ta), 35W (Tc)
Rds On (Maximum) @ Id, Vgs 10.5 mOhm @ 20A, 10V
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting SMD
Manufacturer Package PG-TSDSON-8
Package 8-PowerTDFN
Win Source Part Number 770443-BSZ105N04NS G
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BSZ105N04NS G CAD Model

Description

The BSZ105N04NS G from Infineon Technologies is a medium-popularity electronic component.

  • Package: 8-PowerTDFN
  • Package: PG-TSDSON-8
  • Technology Type: MOSFET
  • Channel Type: N
  • Drain Source Voltage: 40V
  • Current Continuous Drain (Id) @ 25°C: 11A (Ta), 40A (Tc)
