BTS5240L Infineon Technologies BTS5240L label picture BTS5240 real image
Same model may have multiple batches, images only for reference.
BTS5240L Infineon Technologies BTS5240L label picture BTS5240 real image
BTS5240L Infineon Technologies BTS5240L label picture BTS5240 real image
Same model may have multiple batches, images only for reference.

BTS5240L

Part No BTS5240L
Manufacturer Infineon Technologies
Catalog END - OF - LIFE
Description Addendum for PCN-Datasheet 2004-018-A
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Infineon Technologies
Win Source Part Number 1155582-BTS5240L
Manufacturer Homepage www.infineon.com
Family Name BTS 5240
Introduction Date July 10, 2003
ECCN EAR99
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BTS5240L CAD Model

Description

The BTS5240L is a high-side power switch in a PG-TO263-7-1 package.

  • Voltage: Up to 40V
  • Current: 75A
  • Designed to drive: Inductive loads such as motors and solenoids.
  • Protection: Over-temperature, over-current, and short-circuit protection
  • Popularity: High
  • Introduction Date: July 10, 2003
  • Status: Obsolete
