FZ600R12KE3 Real Image
Same model may have multiple batches, images only for reference.

FZ600R12KE3

Part No FZ600R12KE3
Manufacturer Infineon Technologies
Catalog IGBTs - Modules
Description IGBT MODULE 1200V 600A
Datasheet
FZ600R12KE3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies Industrial Power and Controls Americas
Status Active
IGBT Type Trench Field Stop
Configuration Single
VCEO Maximum Collector-Emitter Breakdown Voltage 1200V
Maximum Current Collector 900A
Maximum Power Dissipation 2800W
Collector-emitter saturation voltage(Max) 2.15V @ 15V, 600A
Collector Cut-off Current(Max) 5mA
Input Capacitance (Cies) @ Vce 42nF @ 25V
Input Standard
NTC Thermistor Yes
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting Chassis Mount
Case / Package Module
Win Source Part Number 34394-FZ600R12KE3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian FZ600R12KE3 CAD Model

Description

The Infineon Technologies FZ600R12KE3 is a high-current IGBT module suitable for various industrial applications. It is manufactured by Infineon Technologies Industrial Power and Controls Americas.

  • Mounting Configuration: Chassis Mount
  • Market Popularity: High
  • Supply and Demand: Limited
  • Operating Temperature: -40°C to 125°C (TJ)
  • Maximum Power Dissipation: 2800W
  • Collector-Emitter Saturation Voltage: 2.15V @ 15V, 600A
