IKW40N65ES5XKSA1
Same model may have multiple batches, images only for reference.

IKW40N65ES5XKSA1

Part No IKW40N65ES5XKSA1
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT TRENCH 650V 79A TO247-3
Datasheet
IKW40N65ES5XKSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 51 Weeks
Features IGBT Trench 650 V 79 A 230 W Through Hole PG-TO247-3
Manufacturer Infineon Technologies
Series TrenchStop™
Package Tube
Operating Temperature Range -40°C ~ 175°C (TJ)
Mounting Through Hole
Package TO-247-3
Case / Package PG-TO247-3
Family Name IKW40N65
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Quantity per package 30
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 874496-IKW40N65ES5XKSA1
Ultra Librarian 3D Model Ultra Librarian IKW40N65ES5XKSA1 CAD Model

Description

The Infineon Technologies TrenchStop IGBT is a high-performance electronic component designed to provide reliable and efficient performance for a variety of applications.

  • Voltage Rating: 650V
  • Current Rating: 79A
  • Power Rating: 230W
  • Technology: TrenchStop
  • Operating Temperature: -40°C to 175°C
  • Package: TO-247-3
  • Packaging: Tube

You May Also Be Interested in

IXBH42N170 IXYS – Price, Stock & Datasheet
IXBH42N170
IXYS
IGBT 1700V 80A TO-247AD
Lowest to $31.3869
APT70GR120B2 Microchip Technology – Price, Stock & Datasheet
APT70GR120B2
Microchip Technology
IGBT NPT 1200V 160A TO-247
Need more? Email Us
Picture of IRGP4266D-EPBF
