IPA60R230P6 Real Image IPA60R230P6 Real Image
Same model may have multiple batches, images only for reference.
IPA60R230P6 Real Image IPA60R230P6 Real Image
IPA60R230P6 Real Image IPA60R230P6 Real Image
Same model may have multiple batches, images only for reference.

IPA60R230P6

Part No IPA60R230P6
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description IPA60R230 - 600V COOLMOS N-CHANN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr Infineon Technologies
Series CoolMOS™
Package Bulk
Product Status Active
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 600 V
Current - Continuous Drain (Id) @ 25°C 16.8A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 230mOhm @ 6.4A, 10V
Vgs(th) (Max) @ Id 4.5V @ 530µA
Gate Charge (Qg) (Max) @ Vgs 31 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 1450 pF @ 100 V
Power Dissipation (Max) 33W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Supplier Device Package PG-TO220-3-111
Package / Case TO-220-3 Full Pack
Standard Package 1 pcs
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 603291-IPA60R230P6
Ultra Librarian 3D Model Ultra Librarian IPA60R230P6 CAD Model

Description

The IPA60R230P6 is an N-Channel MOSFET transistor from Infineon Technologies. It belongs to the CoolMOS™ series of transistors, designed for power electronics applications.

  • Drain-Source Voltage (Vdss): 600V
  • Continuous Drain Current (Id): 16.8A @ case temperature of 25°C
  • Maximum On-Resistance (Rds On): 230mOhm @ drain current of 6.4A and gate-source voltage of 10V
  • Gate-Source Threshold Voltage (Vgs(th)): 4.5V @ drain current of 530μA
  • Maximum Power Dissipation: 33W @ case temperature of 25°C
  • Application: Power supplies, motor control, and lighting systems
  • Product Status: Active
