IRF3711STRLPBF Infineon Technologies IRF3711STRLPBF Real Image IRF3711STRLPBF real image
Same model may have multiple batches, images only for reference.
IRF3711STRLPBF Infineon Technologies IRF3711STRLPBF Real Image IRF3711STRLPBF real image
IRF3711STRLPBF Infineon Technologies IRF3711STRLPBF Real Image IRF3711STRLPBF real image
Same model may have multiple batches, images only for reference.

IRF3711STRLPBF

Part No IRF3711STRLPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 20V 110A D2PAK
Datasheet
IRF3711STRLPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 110A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 44nC @ 4.5V
Max Input Capacitance 2980pF @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.1W (Ta), 120W (Tc)
Maximum Rds On at Id,Vgs 6 mOhm @ 15A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 1046486-IRF3711STRLPBF
Family Name IRF3711
Introduction Date March 01, 2004
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRF3711STRLPBF CAD Model

Description

The Infineon Technologies MOSFET is a high-performance electronic component designed for discrete semiconductor products.

  • Polarity: N-Channel
  • Power Dissipation: 3.1W (Ta), 120W (Tc)
  • Drain-Source Breakdown Voltage: 20V
  • Operating Temperature: -55°C to 150°C (TJ)
  • Case/Package: D2PAK
  • Mounting Technology: SMD (SMT)
  • Popularity: High
