IRF530NPBF Infineon Technologies IRF530NPBF Real Image
Same model may have multiple batches, images only for reference.
IRF530NPBF Infineon Technologies IRF530NPBF Real Image
IRF530NPBF Infineon Technologies IRF530NPBF Real Image
Same model may have multiple batches, images only for reference.

IRF530NPBF

Part No IRF530NPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 17A TO-220AB
Datasheet
IRF530NPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 17A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 37nC @ 10V
Max Input Capacitance 920pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 70W (Tc)
Maximum Rds On at Id,Vgs 90 mOhm @ 9A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 093657-IRF530NPBF
Family Name IRF530
Introduction Date July 11, 2006
ECCN EAR99
Country of Origin China, Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRF530NPBF CAD Model

Description

The Infineon Technologies IRF530NPBF MOSFET is a high-performance N-channel power transistor with a maximum drain-source breakdown voltage of 100V and a maximum continuous drain current of 17A @ 25°C.

  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current: 17A @ 25°C
  • Power Dissipation: 70W
  • Package: TO-220AB
  • Applications: power supplies, motor controls, and lighting systems
  • Features: low on-state resistance and a low gate charge
  • Ideal for: high-speed switching applications
  • Operating Temperature: -55°C to 175°C
