Same model may have multiple batches, images only for reference.

IRF7210TRPBF

Name: IRF7210TRPBF
Brand: Infineon Technologies
SKU: 159831
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	IRF7210TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 12V 16A 8-SOIC
Datasheet	IRF7210TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Obsolete(EOL)
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	12V
Continuous Drain Current at 25°C	16A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	2.5V, 4.5V
Gate-Source Threshold Voltage	600mV @ 500μA
Max Gate Charge	212nC @ 5V
Max Input Capacitance	17179pF @ 10V
Maximum Gate-Source Voltage	±12V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	7 mOhm @ 16A, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	017493-IRF7210TRPBF
Family Name	IRF7210
Introduction Date	August 19, 2005
ECCN	EAR99
Estimated EOL Date	Obsolete
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Quantity per package	4k pcs
Ultra Librarian 3D Model	Ultra Librarian IRF7210TRPBF CAD Model

Alternative Products

Description

The Infineon Technologies 017493-IRF7210TRPBF is a P-channel MOSFET that is commonly used in various electronic applications.

Drain-Source Breakdown Voltage: 12V
Continuous Drain Current: 16A (Ta) @ 25°C
Maximum Rds On: 7 mOhm @ 16A, 4.5V
Gate-Source Threshold Voltage: 600mV @ 500μA
Maximum Gate Charge: 212nC @ 5V
Maximum Input Capacitance: 17179pF @ 10V
Package: 8-SO case
Mounting Technology: SMD (SMT)
Package Quantity: 4k pcs per package
