IRF7759L2TRPBF

Name: IRF7759L2TRPBF
Brand: Infineon Technologies
SKU: 461893
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF7759L2TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N-CH Si 75V 160A 15-Pin Direct-FET L8 T/R / MOSFET N-CH 75V DIRECTFET L8
Datasheet	IRF7759L2TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	75V
Continuous Drain Current at 25°C	26A (Ta), 375A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	300nC @ 10V
Max Input Capacitance	12222pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	3.3W (Ta), 125W (Tc)
Maximum Rds On at Id,Vgs	2.3 mOhm @ 96A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	DIRECTFET L8
Dimension	DirectFET Isometric L8
Win Source Part Number	1046718-IRF7759L2TRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRF7759L2
Introduction Date	November 16, 2009
ECCN	EAR99
Country of Origin	Mexico
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian IRF7759L2TRPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRF7759L2TRPBF is an N-channel MOSFET with a maximum power dissipation of 3.3W (Ta) and 125W (Tc).

Power Dissipation: 3.3W (Ta) and 125W (Tc)
Mounting Type: Surface-Mount Device
Package: DirectFET Isometric L8
Drain-Source Breakdown Voltage: 75V
Continuous Drain Current: 26A (Ta) and 375A (Tc) @ 25°C
Gate-Source Threshold Voltage: 4V @ 250μA
Gate Charge: 300nC @ 10V
Lifecycle Status: Active
Popularity: High
