IRF7842TRPBF Real Image IRF7842TRPBF real image297 IRF7842TRPBF Real Image1 IRF7842TRPBF Real Image2 IRF7842TRPBF Real Image3 IRF7842TRPBF Real Image4 IRF7842TRPBF Real Image5 IRF7842TRPBF Real Image6 IRF7842TRPBF Real Image7 IRF7842TRPBF Real Image8 IRF7842TRPBF Real Image9 IRF7842TRPBF Real Image10
Same model may have multiple batches, images only for reference.
IRF7842TRPBF Real Image IRF7842TRPBF real image297 IRF7842TRPBF Real Image1 IRF7842TRPBF Real Image2 IRF7842TRPBF Real Image3 IRF7842TRPBF Real Image4 IRF7842TRPBF Real Image5 IRF7842TRPBF Real Image6 IRF7842TRPBF Real Image7 IRF7842TRPBF Real Image8 IRF7842TRPBF Real Image9 IRF7842TRPBF Real Image10
IRF7842TRPBF Real Image IRF7842TRPBF real image297 IRF7842TRPBF Real Image1 IRF7842TRPBF Real Image2 IRF7842TRPBF Real Image3 IRF7842TRPBF Real Image4 IRF7842TRPBF Real Image5 IRF7842TRPBF Real Image6 IRF7842TRPBF Real Image7 IRF7842TRPBF Real Image8 IRF7842TRPBF Real Image9 IRF7842TRPBF Real Image10
Same model may have multiple batches, images only for reference.

IRF7842TRPBF

Part No IRF7842TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 40V 18A 8-Pin SOIC N T/R / MOSFET N-CH 40V 18A 8-SOIC
Datasheet
IRF7842TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 18A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.25V @ 250μA
Max Gate Charge 50nC @ 4.5V
Max Input Capacitance 4500pF @ 20V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta)
Maximum Rds On at Id,Vgs 5 mOhm @ 17A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 001961-IRF7842TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals, Power Management
Family Name IRF7842
Introduction Date March 27, 2007
ECCN EAR99
Ultra Librarian 3D Model Ultra Librarian IRF7842TRPBF CAD Model

Description

Infineon Technologies presents the IRF7842TRPBF, a MOSFET discrete semiconductor product.

  • Mounting Category: SMD (SMT)
  • Polarity: N-channel
  • Power Dissipation: 2.5W (Ta)
  • Drive Voltage: 4.5V, 10V
  • Status: Active
  • Temperature Range: -55°C to 150°C (TJ)
  • Package: 8-SO
  • Dimension: 8-SOIC (0.154", 3.90mm Width)
  • Drain-Source Breakdown Voltage: 40V
  • Continuous Drain Current: 18A (Ta) @ 25°C
  • Gate-Source Threshold Voltage: 2.25V @ 250μA
  • Maximum Gate Charge: 50nC @ 4.5V
  • Maximum Input Capacitance: 4500pF @ 20V
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Rds On @ Id,Vgs: 5 mOhm @ 17A, 10V
  • Supply and Demand Status: Balanced
  • Application: Computers & Computer Peripherals and Power Management
