Same model may have multiple batches, images only for reference.

IRF9333PBF

Name: IRF9333PBF
Brand: Infineon Technologies
SKU: 1028139
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF9333PBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 30V 9.2A 8SO / P-Channel 30 V 9.2A (Ta) 2.5W (Ta) Surface Mount 8-SO
Datasheet	IRF9333PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr	Infineon Technologies
Series	HEXFET®
Package	Tube
FET Type	P-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	30 V
Current - Continuous Drain (Id) @ 25°C	9.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	19.4mOhm @ 9.2A, 10V
Vgs(th) (Max) @ Id	2.4V @ 25µA
Gate Charge (Qg) (Max) @ Vgs	38 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	1110 pF @ 25 V
Power Dissipation (Max)	2.5W (Ta)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting	SMD (SMT)
Supplier Device Package	8-SO
Package / Case	8-SOIC (0.154", 3.90mm Width)
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Other Names	SP001554504
Standard Package	3,800
Win Source Part Number	1028139-IRF9333PBF
Ultra Librarian 3D Model	Ultra Librarian IRF9333PBF CAD Model

Alternative Products

Description

The Infineon Technologies 1028139-IRF9333PBF is a P-Channel MOSFET transistor with a HEXFET® series.

Manufacturer: Infineon Technologies
Product Name: 1028139-IRF9333PBF
Type: P-Channel MOSFET transistor
Series: HEXFET®
Drain to Source Voltage (Vdss): 30 V
Continuous Drain Current (Id) @ 25°C: 9.2A (Ta)
Rds On (Max) @ Id, Vgs: 19.4mOhm @ 9.2A, 10V
Gate Charge (Qg) @ Vgs: 38 nC @ 10 V
Input Capacitance (Ciss) @ Vds: 1110 pF @ 25 V
Package: 8-SOIC
Applications: power management systems, motor control, and DC-DC converters.
