IRFB4020PBF Real Image IRFB4020PBF Real Image
Same model may have multiple batches, images only for reference.
IRFB4020PBF Real Image IRFB4020PBF Real Image
IRFB4020PBF Real Image IRFB4020PBF Real Image
Same model may have multiple batches, images only for reference.

IRFB4020PBF

Part No IRFB4020PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 200V 18A TO-220AB
Datasheet
IRFB4020PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 200V
Continuous Drain Current at 25°C 18A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4.9V @ 100μA
Max Gate Charge 29nC @ 10V
Max Input Capacitance 1200pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 100W (Tc)
Maximum Rds On at Id,Vgs 100 mOhm @ 11A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 069452-IRFB4020PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRFB4020PBF CAD Model

Description

The Infineon Technologies IRFB4020PBF is an N-Channel MOSFET designed for use in a variety of applications.

  • Maximum Continuous Drain Current: 18A
  • Mounting: Through-Hole
  • Package: TO-220AB
  • On-Resistance: 100mΩ
  • Maximum Power Dissipation: 100W
  • Operating Temperature Range: -55°C to 175°C (TJ)
