Same model may have multiple batches, images only for reference.

IRFP4868PBF

Name: IRFP4868PBF
Brand: Infineon Technologies
SKU: 160599
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	IRFP4868PBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N-CH 300V 70A 3-Pin(3+Tab) TO-247AC Tube / MOSFET N-CH 300V 70A TO-247AC
Datasheet	IRFP4868PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	300V
Continuous Drain Current at 25°C	70A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	5V @ 250μA
Max Gate Charge	270nC @ 10V
Max Input Capacitance	10774pF @ 50V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	517W (Tc)
Maximum Rds On at Id,Vgs	32 mOhm @ 42A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	Through Hole
Case / Package	TO-247AC
Dimension	TO-247-3
Win Source Part Number	087508-IRFP4868PBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	IRFP4868
Introduction Date	October 30, 2012
ECCN	EAR99
Country of Origin	China, Germany, Mexico, Republic of Korea, Taiwan, United Kingdom
Halogen Free	Compliant
Estimated EOL Date	2028
Ultra Librarian 3D Model	Ultra Librarian IRFP4868PBF CAD Model

Description

The Infineon Technologies IRFP4868PBF MOSFET is a high-performance N-channel power MOSFET with a drain-source breakdown voltage of 300V and a maximum continuous drain current of 70A @ 25°C.

Drain-Source Breakdown Voltage: 300V
Maximum Continuous Drain Current: 70A @ 25°C
Package: TO-247AC package
Gate Charge: 270nC @ 10V
Compliance: Halogen-free and RoHS directive
Popularity: high popularity rating
