IRFR3704ZTRPBF Real Image IRFR3704ZTRPBF real image359 IRFR3704ZTRPBF Real Image
Same model may have multiple batches, images only for reference.
IRFR3704ZTRPBF Real Image IRFR3704ZTRPBF real image359 IRFR3704ZTRPBF Real Image
IRFR3704ZTRPBF Real Image IRFR3704ZTRPBF real image359 IRFR3704ZTRPBF Real Image
Same model may have multiple batches, images only for reference.

IRFR3704ZTRPBF

Part No IRFR3704ZTRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 20V 60A DPAK
Datasheet
IRFR3704ZTRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 60A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.55V @ 250μA
Max Gate Charge 14nC @ 4.5V
Max Input Capacitance 1190pF @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 48W (Tc)
Maximum Rds On at Id,Vgs 8.4 mOhm @ 15A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 001280-IRFR3704ZTRPBF
Family Name IRFR3704
Introduction Date June 29, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRFR3704ZTRPBF CAD Model

Description

The Infineon Technologies IRFR3704ZTRPBF MOSFET is a N-channel power transistor from Infineon Technologies, which has been discontinued and is not for new designs.

  • Maximum power dissipation: 48W (Tc)
  • Drain-source breakdown voltage: 20V
  • Continuous drain current: 60A (Tc) @ 25°C
  • Gate-source threshold voltage: 2.55V @ 250μA
  • Maximum Rds On @ Id,Vgs: 8.4 mOhm @ 15A, 10V
  • Package: D-Pak
  • Dimension: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Packaging: reel-tr packaging
  • Category: Discrete Semiconductor Products
  • Market popularity: high
