IRFR3710ZTRPBF Real Image IRFR3710ZTRPBF real image360 IRFR3710ZTRPBF real image361 IRFR3710ZTRPBF Real Image
Same model may have multiple batches, images only for reference.
IRFR3710ZTRPBF Real Image IRFR3710ZTRPBF real image360 IRFR3710ZTRPBF real image361 IRFR3710ZTRPBF Real Image
IRFR3710ZTRPBF Real Image IRFR3710ZTRPBF real image360 IRFR3710ZTRPBF real image361 IRFR3710ZTRPBF Real Image
Same model may have multiple batches, images only for reference.

IRFR3710ZTRPBF

Part No IRFR3710ZTRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 42A DPAK
Datasheet
IRFR3710ZTRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 42A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 100nC @ 10V
Max Input Capacitance 2930pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 140W (Tc)
Maximum Rds On at Id,Vgs 18 mOhm @ 33A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 017680-IRFR3710ZTRPBF
Family Name IRFR3710
Introduction Date July 31, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRFR3710ZTRPBF CAD Model

Description

The Infineon Technologies IRFR3710ZTRPBF is an N-channel MOSFET that features a drain-source breakdown voltage of 100V and a continuous drain current of 42A at 25°C.

  • Package: D-Pak
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Rds On: 18 mOhm @ 33A, 10V
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Gate Charge: 100nC @ 10V
  • Maximum Input Capacitance: 2930pF @ 25V
  • Supply and Demand Status: balanced
  • Estimated EOL Date: 2024
