Same model may have multiple batches, images only for reference.

IRFS3206TRRPBF

Name: IRFS3206TRRPBF
Brand: Infineon Technologies
SKU: 160889
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRFS3206TRRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 60V 120A D2PAK / Trans MOSFET N-CH Si 60V 210A 3-Pin(2+Tab) D2PAK T/R
Datasheet	IRFS3206TRRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	60V
Continuous Drain Current at 25°C	120A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 150μA
Max Gate Charge	170nC @ 10V
Max Input Capacitance	6540pF @ 50V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	300W (Tc)
Maximum Rds On at Id,Vgs	3 mOhm @ 75A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	D2PAK
Dimension	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number	089926-IRFS3206TRRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	IRFS3206
Introduction Date	June 05, 2006
ECCN	EAR99
Country of Origin	China, Republic of Korea
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian IRFS3206TRRPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRFS3206TRRPBF MOSFET is a N-channel power transistor from Infineon Technologies, ideal for use in power management applications.

Power Dissipation: 300W (Tc)
Drain-Source Breakdown Voltage: 60V
Continuous Drain Current: 120A (Tc) @ 25°C
Gate-Source Threshold Voltage: 4V @ 150μA
Maximum Rds On at Id,Vgs: 3 mOhm @ 75A, 10V
Package: D2PAK package
Dimension: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Packaging: reel-tr
