IRFS4310TRLPBF Real Image IRFS4310TRLPBF Real Image
Same model may have multiple batches, images only for reference.
IRFS4310TRLPBF Real Image IRFS4310TRLPBF Real Image
IRFS4310TRLPBF Real Image IRFS4310TRLPBF Real Image
Same model may have multiple batches, images only for reference.

IRFS4310TRLPBF

Part No IRFS4310TRLPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 130A D2PAK / Trans MOSFET N-CH 100V 130A 3-Pin(2+Tab) D2PAK T/R
Datasheet
IRFS4310TRLPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 130A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 250nC @ 10V
Max Input Capacitance 7670pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 300W (Tc)
Maximum Rds On at Id,Vgs 7 mOhm @ 75A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 111578-IRFS4310TRLPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRFS4310
Introduction Date November 03, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IRFS4310TRLPBF CAD Model

Description

The Infineon Technologies IRFS4310TRLPBF is a N-channel MOSFET.

  • Description: It is a high-performance power MOSFET that is designed to meet the requirements of synchronous buck converters for modern notebook CPU power.
  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current: 130A @ 25°C
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Rds On @ Id,Vgs: 7 mOhm @ 75A, 10V
  • Package: D2PAK, TO-263-3, D2Pak (2 Leads + Tab), TO-263AB.
  • Status: commonly used and has a balance of supply and demand.
