Same model may have multiple batches, images only for reference.

IRFSL4010PBF

Name: IRFSL4010PBF
Brand: Infineon Technologies
SKU: 605361
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	IRFSL4010PBF
Manufacturer	Infineon Technologies
Catalog	FETs - Single
Description	High Efficiency Synchronous Rectification in SMPS \| MOSFET N-CH 100V 180A TO-262
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	100V
Id - Continuous Drain Current	180A
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Maximum) at Id, Vgs	4.7mOhm at 106A, 10V
Gate Source Voltage(th) (Maximum) at Id	4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	215nC at 10V
Gate Source Voltage (Maximum)	±20V
Input Capacitance (Ciss) (Maximum) at Vds	9575pF at 50V
Power Dissipation (Maximum)	375W
Temperature Range - Operating	-55°C ~ 175°C
Mounting Style	Through Hole
Supplier Device Package	TO-262
Manufacturer Package	TO-262-3 Long Leads, I2Pak, TO-262AA
Manufacturer Pack Quantity	1,000
MSL Level	1 (Unlimited)
Win Source Part Number	1188049-IRFSL4010PBF
Manufacturer Homepage	www.irf.com
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian IRFSL4010PBF CAD Model

Alternative Products

Description

The IRFSL4010PBF is a limited supply electronic component manufactured by Infineon Technologies.

Win Source Part Number: 1188049-IRFSL4010PBF
Mounting Style: Through-Hole
Technology: MOSFET
FET Feature: -
Transistor Polarity: N-Channel
Supplier Device Package: TO-262
Drive Voltage (Max Rds On, Min Rds On): 10V
Temperature Range: -55°C to 175°C
Power Dissipation (Maximum): 375W
Vds - Drain-Source Breakdown Voltage: 100V
Id - Continuous Drain Current: 180A
Rds On (Maximum) @ Id, Vgs: 4.7mOhm @ 106A, 10V
Gate Source Voltage(th) (Maximum) @ Id: 4V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs: 215nC @ 10V
Gate Source Voltage (Maximum): ±20V
Input Capacitance (Ciss) (Maximum) @ Vds: 9575pF @ 50V
