IRG4PH50KDPBF Real Image IRG4PH50KDPBF real image
IRG4PH50KDPBF Real Image IRG4PH50KDPBF real image
Same model may have multiple batches, images only for reference.

IRG4PH50KDPBF

Part No IRG4PH50KDPBF
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT 1200V 45A 200W TO247AC
Datasheet
IRG4PH50KDPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Bulk
Status Active
VCEO Maximum Collector-Emitter Breakdown Voltage 1200V
Maximum Current Collector 45A
Pulsed Collector Current 90A
Collector-emitter saturation voltage(Max) 3.5V @ 15V, 24A
Maximum Power Dissipation 200W
Total Switching Energy(Ets) 3.83mJ (on), 1.9mJ (off)
Input Type Standard
Gate Charge 180nC
Turn-on and Turn-off delay time 87ns/140ns
Testing Conditions 800V, 24A, 5 Ohm, 15V
Reverse Recovery Time (trr) 90ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-247AC
Win Source Part Number 016638-IRG4PH50KDPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRG4PH50KDPBF CAD Model

Description

The Infineon Technologies IRG4PH50KDPBF is a TO-247AC packaged IGBT transistor with a VCEO maximum collector-emitter breakdown voltage of 1200V and a maximum current collector of 45A.

  • Maximum Power Dissipation: 200W
  • Gate Charge: 180nC
  • Reverse Recovery Time (trr): 90ns
  • Input Type: Standard
  • Operating Temperature: -55°C to 150°C (TJ)
  • Collector-Emitter Saturation Voltage (Max): 3.5V @ 15V, 24A
  • Total Switching Energy (Ets): 3.83mJ (on), 1.9mJ (off)
  • Turn-On and Turn-Off Delay Time: 87ns/140ns
  • Supply and Demand Status: Limited
