IRL1004STRRPBF Infineon Technologies IRL1004STRRPBF Real Image IRL1004STRRPBF label picture 2 IRL1004STRRPBF real image
Same model may have multiple batches, images only for reference.
IRL1004STRRPBF Infineon Technologies IRL1004STRRPBF Real Image IRL1004STRRPBF label picture 2 IRL1004STRRPBF real image
IRL1004STRRPBF Infineon Technologies IRL1004STRRPBF Real Image IRL1004STRRPBF label picture 2 IRL1004STRRPBF real image
Same model may have multiple batches, images only for reference.

IRL1004STRRPBF

Part No IRL1004STRRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH Si 40V 130A 3-Pin(2+Tab) D2PAK T/R / MOSFET N-CH 40V 130A D2PAK
Datasheet
IRL1004STRRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 130A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 100nC @ 4.5V
Max Input Capacitance 5330pF @ 25V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 3.8W (Ta), 200W (Tc)
Maximum Rds On at Id,Vgs 6.5 mOhm @ 78A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 1047419-IRL1004STRRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRL1004
Introduction Date July 19, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian IRL1004STRRPBF CAD Model

Description

The Infineon Technologies IRL1004STRRPBF is an N-channel MOSFET with a drain-source breakdown voltage of 40V and a continuous drain current of 130A @ 25°C.

  • Channel Type: N-channel
  • Drain-Source Breakdown Voltage: 40V
  • Continuous Drain Current: 130A @ 25°C
  • Maximum Rds On @ Id,Vgs: 6.5 mOhm @ 78A, 10V
  • Power Dissipation: 3.8W (Ta), 200W (Tc)
  • Drive Voltage: 4.5V, 10V
  • Package: D2PAK
  • Mounting Technology: SMD (SMT)
  • Category: Discrete Semiconductor Products
  • Status: Obsolete (EOL)
  • Temperature Range: -55°C to 175°C (TJ)
  • Maximum Gate-Source Voltage: ±16V
  • Maximum Gate Charge: 100nC @ 4.5V
  • Maximum Input Capacitance: 5330pF @ 25V
  • Supply and Demand: Balanced
